    New Design 24W 1A 24V Wall Mount Power Adapters KC IEC61558 Certificated

    Ask Lasest Price
    Brand Name : Analog
    Model Number : BZ024-240100-AK
    Certification : KC/KFC
    Price : 1-5USD
    Payment Terms : T/T
    Supply Ability : 1,600,000~1,800,000PCS/Month
    Delivery Time : 10-25 work days
    • Product Details
    • Company Profile

    New Design 24W 1A 24V Wall Mount Power Adapters KC IEC61558 Certificated


    New Design of 24W 1A 24V Wall Mounted Power Adapter KC Certificate IEC61558/IEC60335 Approved


    What is A power adapter used for?


    Power adapter, also known as external power supply, is a power supply voltage conversion equipment for small portable electronic equipment and electronic appliances. It is commonly used in small electronic products such as mobile phones, LED field and laptops.Analog Power is a professional ac dc manufacturer in Dongguan China.


    Product Description


    Output Voltage(VDC)Output Current (A)Output Power(W )
    5.0~7.90.01~3.0023.70
    8.0~11.00.01~3.0027.00
    11.1~15.00.01~2.5030.00
    15.1~24.00.01~1.5030.00
    24.1~32.00.01~1.2430.00


    Safety Certificate and EMC


    BZ024 UL1310 Certificate.pdf


    Application: Air Purifier/Cleaner/Sweeper/Window Wiper



    Specification Datasheet Table


    ItemSpecification Datasheet TableNote
    DescriptionProduct namesingle-output switch power adapter
    Product typeWall mount/Desktop/Interchange
    ModelGQ48-240200-AG
    Supply Ability1,600,000~1,800,000PCS/month
    Applicationas per customer requirments,etc
    Mechanical PerformanceColorBlack or White
    DimensionsSubjected to final design
    Output DC Connector5.5x2.1x10mm optional
    DC Cord / DC JackL=1.2m / 1.5m or Customized
    Plug typeEU ,UK, US, AU, KC, PSE...
    Electrical PerformanceOutput Voltage & Frequency24V
    Output Current1A
    Output Power24W
    Ripple/Noise
    300mVp-p Max.
    Input Voltage & Frequency90VAC~264VAC, 47~63HZ
    Maximum AC CurrentPlease refer to the specification datasheet for approval
    Input Inrush Current40A(RMS) Max, full load tested @AC230V 50HZ
    EfficiencyVI
    ProtectionOVP,OCP,OTP,SCP & Input Protection
    Environmental requirementsOperating Temperature0~40 ℃,
    Storage Temperature-40~70 ℃
    Operating Humidity5%~90% Non-condensing
    Storage Humidity5%~90% Non-condensing
    ReliabilityWarranty2 year (about 2.28 years for 24-hour-operation a day)
    MTBF>20,000 hour
    Insulation Resistanc> 30MΩ@500VDC; 60S
    Hi-PotMeet different safety standard
    Leakage Current0.25mA Max, full load tested @AC230V 50HZ
    Compliance with EU directives law & regulationsRoHS,REACH,PAHS
    Safety StandardCertificateUL/ETL/FCC/CE/ GS/UKCA/ PSE/ KC/ SAA/ EAC/BIS/ICBR
    StandardsIEC61558/IEC60335/IEC61347/ETL1310/ IEC62368,GB4943, GB4706,etc...
    EMCEN55014-1/EN55014-2 compliance
    ESD(Air discharge@ 8KV, Contact discharge@ 6KV,(IEC61000-4-2)
    Surge±1KV @ common or different mode

    Application


    Application FieldProducts including but not limited to

    Home/Household Appliances

    (IEC61558)

    Robot Vacuum Cleaner, Floor Cleaning Robots,Window Cleaning Robots,Steam Mops,Electric Mops,Cold-air Cooler,Water Purifier,Air purifier,Dehumidifier, Humidifier,Aroma Diffuser,Mosquito Killer,Ice Maker
    Led Lighting(IEC61347)Led Power Supply,Led Driver,Table/Desk Lamp,Led Strip Light,Led Desktop Fan,Grow Light,Led Plant Growth Lamp,OSRAM led,

    IT Communications Equipment

    (IEC62368=IEC60950+IEC60065)

    Router,Switch,Mobile phones,Tablet PC,Network, Radio and Television Equipment,PoE...
    Audio Equipment(IEC62368)Speakers,Recording Machine,Microphone
    Video Equipment(IEC62368)STB TV box,Computers
    Security Device(IEC62368)Monitor,CCTV cameras,

    Household and Similar

    Electrical Appliances

    (IEC60335)

    Electrical devices with lithium battery power supply requires battery charge adapter
    Power Units( ETL1310)Electronic, electrical, mechanical or electron-mechanical products
    Other IndustriesUAV,Drones,Balance Car,Unicycle,Segway,PS4 Game Players Home Healthcare ,Cash registers/Counting Machine,Counterfeit Detector

    More Connector type/More Plug type


    Plug Type Identification
    Series No.Plug Type StyleCodeDescription
    A_Front style plugAUUS front style AC Plug
    AAAustrialian front style AC Plug
    AGEuropean front style AC Plug
    AJJapanese front style AC Plug
    AKKorean front style AC Plug
    ABBritish front style AC Plug
    ARRussian front style AC Plug
    AXInterchangeable front style AC Plug
    ACChinese front style AC Plug
    ABSSingaporean plug(changeable)
    AA1Argentina front style AC Plug
    AUMMexico front style AC plug
    H_or C_Side style plugHU/CUUS side style AC Plug
    HA/CAAustrialian side style AC Plug
    HG/CGEuropean side style AC Plug
    HJ/CJJapanese side style AC Plug
    HK/CKKorean side style AC Plug
    HB/CBBritish side style AC Plug
    HR/CRRussian side style AC Plug
    HX/CXInterchangeable side style AC Plug
    HC/CCChinese side style AC Plug
    Z_Inline style plugZUUS inline style AC Plug
    ZAAustrialian inline style AC Plug
    ZGEuropean inline style AC Plug
    ZJJapanese inline style AC Plug
    ZKKorean inline style AC Plug
    ZBBritish inline style AC Plug
    ZRRussian inline style AC Plug
    ZXInterchangeable inline style AC Plug
    ZCChinese inline style AC Plug
    E _Applicance typeE1Input with type C14/C6 used
    E2Desk-top input with type C8 used
    E3Fixed power cord ungrounded
    E4Fixed power cord grounded

    We can customize the plug according to your need, such as US / EU / UK / AU / KR /JP and other regions


    Adantages
    1. AC/DC Plug--Contains conductive metal shrapnel to improve the contact stability of the plug
    2. End Buffer Design -- After rigorous bending experiments,the Power Adapter is strong and resistant for pulling
    3. Bold pure copper wire --Transmission voltage loss is smaller and much more stable
    4. Improve heat dissipation performance by adequate spacing
    5. Improve efficiency by using vertical anti-interference high frequency transformer
    6. We went through multiple tests to make sure the product you recive is of great quality
